Description
General Specifications
- Raw material: Thermoplastic U-PVC
- Compression resistance : 320 N / 60 Sec / 23±2 °C
- Impact resistance: 2 Joule
- Operating temperature: -25 to +60 C0
- Colour: White RAL 9010
- Insulation Strength: 2000V / 50 Hz / 15 min.
- Insulation Resistance: >100 MΩ / 60 Sec / 500 V
- IP Ingress Protection: IP66
Features
- UV resistant
- Easy install, paintable
- Economic and adaptable
- Resistant to acids, oils and greases
- Non-conductive
- Nonflammable
- Corrosion resistant
- Lead-Free environment friendly PVC material
- With wire type available
- Orange color available
- Standards EN 61386-21
| Size | Code | d (mm) | D (mm) | Tolerance | Quantity/Pack (m) | Volume (m3) | Weight (kg) |
|---|---|---|---|---|---|---|---|
| Ø14 | SC6014000 | 14 | 18,1 | + 0 / – 0,3 | 100 | 0,043 | 3,7 |
| Ø16 | SC6016000 | 16 | 19,8 | + 0 / – 0,3 | 100 | 0,048 | 3,8 |
| Ø18 | SC6018000 | 18 | 22,1 | + 0 / – 0,3 | 50 | 0,055 | 4,3 |
| Ø20 | SC6020000 | 20 | 24,2 | + 0 / – 0,3 | 50 | 0,062 | 4,6 |
| Ø25 | SC6025000 | 25 | 28,9 | + 0 / – 0,4 | 50 | 0,068 | 4,8 |
| Ø32 | SC6032000 | 32 | 36 | + 0 / – 0,4 | 50 | 0,075 | 4,9 |
