Description
Door & Division Panels
12 mm solid grade laminate (SGL) panels provide maximum protection against water and scratch.
Lock
Stainless steel overlaid indicator bolt with emergency release facility.
Hinge
Stainless steel, self-closing hinges, fixed with three locking screw for straight line door system.
Legs
Stainless steel floor mounted with screw connection and fixed to the panel with minimal panel overlap to front. Adjustable to accommodate uneven floor levels.
Header Profile & Fixings
53*50 mm polished aluminium with integral channel to receive SGL panels. 18*25mm “U” profile is used on wall-cubicle and cubicle-cubicle intersection points. All fixings are stainless steel.
Edge treatment
Edges are machined to a black smooth finish with increased radiused corner safety details and visual effect to pilasters and doors.
Dimensions
Toilet cubicle overall height is 1940-1990mm including 150-100 mm under panel clearance.
