Description
PRODUCT FEATURES
- The world’s first circular racing tube slide
- High speed, tube racing, multi lane ride
- High capacity ride {The unique double slide feature effectively doubles capacity over ‘regular’ water park slides}
- A truly racing slide {Circular racing with turns, twists}
- Fully open version available
- Fully enclosed version available for a completely dark attraction
- Half closed- half open version available
- Natural Light Effects system applicable
- Launch conveyor or tower available as an entry option {Launch conveyor guarentees simultaneous riding experience}
- Strong spectator appeal
- Theming options available
- The entry part can be combined with Ø1400 Series
- The exit part can be combined with Wide Slide Series
- Configuration enables to choose between a pool or a run-out for the exit part
- Each slide can be used with both single and double tubes {Share the experience or try it alone}
TECHNICAL SPECIFICATIONS
Part 1:
Depth : 500 / 750 / 1500 / 1400 / 730mm (20 / 30 / 59 / 55 / 29 in) Width : 2×1400 / 1400 / 6000 / 4000mm (2×55 / 55 / 236 / 158 in) Slope : 10/40 % Capacity : 180x2x2 Riders/h Exit : Pool or Run-Out Flow rate (Start) : 360 m3/h (1585 USGPM)
Part 2 :
Depth : 500 / 750 / 1500 / 1400mm (20 / 30 / 59 / 55 in) Width : 2×1400 / 1400mm (2×55 / 55 in) Slope : 10/20 % Capacity : 180x2x2 Riders/h Exit : Pool or Run-Out Flow rate (Start) : 400 m3/h (1761 USGPM)
*These specs may change depending on the slide’s design.
