Description
General Specifications
- Raw Material: ABS
- Quality Standart: EN 61439-1, EN 61439-2
- Color: RAL 9010
- Operating Temperature: -15ºC / +60ºC
- Door Opening Angle: 180º
- Protection Class: IP40
- Fire Resistance: Up to 650 ºC
- Insulating Class: Class II
- Circuit Breaker Rail: Galvanised Steel
Features
- Rustproof, no need painting and maintenance.
- Dielectric, safety
- Flameproof, self-extinguishing.
- Resistant to atmosphere conditions.
- Wide internal space, selected designs.
- Resistant to heat and impact.
- Equipped with earthing and installation accessories.
- Installation of insulated earthing is optional.
- Halogen free type is optional.
- Easy installation.
| Size | Code | W (m) | H (m) | L (m) | Quantity/Pack | Volume (m3) | Weight (kg) |
|---|---|---|---|---|---|---|---|
| 2-6 | FS1102006 | 0,145 | 0,189 | 0,104 | 30 | 0,003 | 10,8 |
| 9 | FS1109000 | 0,107 | 0,313 | 0,215 | 20 | 0,007 | 10,9 |
| 12 | FS1112000 | 0,314 | 0,1 | 0,221 | 16 | 0,007 | 12 |
| 16 | FS1116000 | 0,293 | 0,111 | 0,239 | 16 | 0,008 | 13,6 |
| 24 | FS1124000 | 0,346 | 0,107 | 0,318 | 8 | 0,012 | 10,5 |
| 36 | FS1136000 | 0,323 | 0,101 | 0,448 | 5 | 0,015 | 16,9 |
