Description
Non-Flammable
Paintable
Adaptable
Easy Installation
Modular System Cable Trunkings
Discover the future of cable management with our premium Modular System Cable Trunkings. Made from the finest PVC UL94 with V0 M1 fire resistance, our trunking guarantees safety and durability. It effortlessly handles temperatures from a chilling -25°C to a hot 65°C, and with its impactful resistance up to 0.5 Joule, it’s built to last. In an elegant White RAL 9010 shade, it not only integrates seamlessly into most designs but also offers features like UV resistance, liquid protection, and non-conductivity. Plus, with its adaptability and easy installation, your setup will look sleek in no time.
*Easy to add sockets and outlets *Up to 4 compartment. *Foil tape protected and inner cover.
| Size | Code | W (mm) | H (mm) | Quantity/Pack (m) | Volume (m3) | Weight (kg) | Loading Area (mm2) | Loading Capacity (kg / m) | |
|---|---|---|---|---|---|---|---|---|---|
| A SERIES | 100 x 50 | CT1100050 | 100 | 50 | 16 | 0,067 | 16 | 4431,2 | 22,5 |
| A SERIES ADHESIVE | 100 x 50 | CT2100050 | 100 | 50 | 16 | 0,067 | 16,3 | 4431,2 | 22,5 |
| A SERIES | 100 x 50 | CT3100050 | 100 | 50 | 16 | 0,067 | 19,6 | 4367,9 | 22,8 |
| A SERIES ADHESIVE | 100 x 50 | CT4100050 | 100 | 50 | 16 | 0,067 | 19,8 | 4367,9 | 22,8 |
| A SERIES | 100 x 50 | CT5100050 | 100 | 50 | 6 | 0,026 | 7,315 | 4367,9 | 22,8 |
| A SERIES ADHESIVE | 100 x 50 | CT6100050 | 100 | 50 | 6 | 0,026 | 7,399 | 4367,9 | 22,8 |
